Charming 2,727 Sq. Ft. Home with Master Suite and Outdoor Living

Plan Number:

O5002-A

4
Bedrooms
3
Full Baths
2727
SQ FT
LOW PRICE GUARANTEE

House Plan Specifications

  • Total Living:  2727
    1st Floor:  2727
    Lanai:  690
    Front Porch:  49
  • Garage:  566
    Garage Bays:   2
    Garage Load:   Front
  • Bedrooms:   4
    Bathrooms:   3
  • Foundation:   Slab
    Wall Framing:
    Roof Framing:   Truss
    Roof Pitch:   6:12
    Roof Pitch:  6:12
    Exterior Siding:   Stucco Exterior
  • Width of House:  60''
    Depth of House:  79' 10''
    Building Height:  25''

Key Features:

  • Covered Front Porch
  • First Floor Master Suite
  • Home Office/Study
  • Keeping/Family Room
  • Kitchen Island
  • Master Bath-Double Vanity Sink
  • Mud Room
  • Outdoor Kitchen
  • Rear Porch
  • Split Bedroom
  • Walk In Closets
  • Walk-in Closet
