Shelton 42391 is a single-story ranch house plan designed with 1,603 square feet of heated living space and a 42-foot wide by 51-foot, 4-inch deep footprint. This traditional design emphasizes a compact, efficient layout that minimizes wasted circulation while maximizing usable residential square footage for narrow or standard-sized lots.
The interior configuration centers on an open-concept core where the kitchen, equipped with a central island, maintains direct sightlines into the keeping room. A masonry fireplace serves as the focal point of this social area, while the formal dining space remains adjacent for ease of access. The split-bedroom layout ensures the primary suite maintains a private orientation away from the two secondary bedrooms, enhancing noise reduction and acoustic separation.
Functional zoning is prioritized through a dedicated home office, which provides a quiet environment for remote work, and a mudroom that serves as a transition zone between the interior and the exterior. The first-floor laundry room is positioned for access from the main living quarters, streamlining household maintenance. With 9-foot ceilings throughout the main level, the interior volume achieves a consistent sense of scale that complements the efficient floor plan.
Structural specifications include a 23-foot, 11-inch maximum building height and an 8:12 roof pitch, which provides a classic profile and allows for an unfinished basement foundation. This basement level offers significant potential for future expansion, providing additional square footage that can be adapted to meet evolving storage or recreational requirements.
A front-load 2-car garage provides 473 square feet of vehicle and equipment storage, ensuring the main structure retains a manageable lot coverage footprint. The inclusion of a rear patio extends the living area outdoors, facilitating a connection to the backyard without sacrificing the internal privacy of the primary suite or the home office.
Key Features: 1,603 sq ft, 3 bedrooms, 1 full bathroom, split-bedroom layout, first-floor primary suite, home office, mudroom, 2-car front-load garage, 9-foot ceilings, unfinished basement, 8:12 roof pitch.
