Floor Plan

Spacious Family Home (4,140 sq ft) with Elegant Features

Imagine the Grandeur, of a European Castle Home, with all the welcoming modern amenities. The connection between old and new remains opulent & impressive. The exterior brings you close with grand stucco columns and a cooper roof. All of this is highlighted by the siding and shake facade.

Upon entering the Smoke Rise you are conscious of such an Exclusive House Plan. Everyone is greeted by a magnificent two story foyer, accompanied by an opulent floating staircase. This Exclusive Castle House Plan allows for the staircase to pour you onto the Second Floor.

The splendor of the Foyer flows seamlessly into the oval dining area. From this location in this Neoclassical Home Plan, you are visualizing a Grand Room. To the Left of the Foyer awaits a Library of solitude and ornately rich walls.

This Exclusive House Plan sweeps into the kitchen. This sprawling circuit includes the Family Room and Breakfast Area, which give way to the Kitchen. As a cook, who daily preps and prepares, you will find yourself at ease. Today's family spends a significant amount of time congregating in the Kitchen, and its surrounding areas. This certifies that this family triangle is an imperative part of family flow.

  • Set of Back Stairs for friends & family

  • Ample Floating Cabinets

  • Small computer space for logging recipes, or finances

  • Access to Covered Veranda & Deck

  • Access to Elevator for multiple uses

Your Master Suite for this Neoclassical House Plan lays in exhibition just beyond the Library. The Master Suite features trey ceilings as you enter the Sitting Area; with a hand crafted fireplace. The Home Style delivers access to the deck as well.

  • Intimate soaking tub

  • His & Her Walk in Closets

  • Contains a small foyer entering into the Master En-Suite.

  • Inviting tub for soaking

This Luxury Home Style offers a rare view of the first floor; you are given the opportunity to see both the Grand Room and the Library from a different vantage point. Now you take notice of the additional regal Bedrooms two through four. The Exclusive Home Plan calls for all three bedrooms to be generous in size. In addition there is a future Guest or Play Room with Deck access.

  • Private Baths

  • Walk In Closets

As you finish your tour of the Smoke Rise, you are introduced to a Home Style that offers a full size Daylight Basement. The Castle Home Plan allows for a complete Future second Master Suite or In-Law Suite. In addition there are many extras….

  • Future Entertainment / Billiards / Game Room

  • Future Gym

  • Future Wet Bar

  • Future Theatre

  • Future Wine Room

The Smoke Rise Home Plan is one of the many popular plans that has elevated our Home Plan Portfolio to be one of the largest and most prized luxury homes.

House Plan Specifications

  • Total Living (heated area):  4140 sq ft
    1st Floor:  2912 sq ft
    2nd Floor:  1228 sq ft
    Basement:  2838 sq ft
  • Garage:  720 sq ft
    Garage Load:   Side
  • Bedrooms:   4
    Bathrooms:   4
    Half Bathrooms:   1
  • Foundation:   Basement
    Wall Framing:
  • Width of House:  80'
    Depth of House:  81'
  • First Floor Ceiling Height:  10'
    Second Floor Ceiling Height:  10'
    Vault Height:  12'

Key Features

  • First Floor Master Suite
  • Two Master Suites
Modify this plan to make it perfect
Our hassle-free process makes it easy to modify your dream home. To receive an estimate please submit your request using the link below.
Submit a Modification Request
Cost to build estimate
$0.00
$40.00
100% discount for new customers this month!
Receive a personal estimate in two minutes instead of 2 days as many competitors offer. Just submit your request using the link below.
Get Your Estimate
Plan Number: A387-A
Spacious Family Home (4,140 sq ft) with Elegant Features
4 Bedrooms
4 Full Baths
1 Half Baths
4140 SQ FT
2 Stories
Second Floor
Basement
House Plan Formats Explained

PDF (Single Build)

A complete set of working drawings delivered in digital PDF format. This option comes with a license to build ONE home and includes a copyright release for printing unlimited sets of plans and making modifications.

CAD + PDF (Single Build)

A complete set of working drawings delivered in digital DWG and PDF formats. AutoCAD files are used by design professionals to make significant modifications or engineering calculations to the plan. This option comes with a license to build ONE home and includes a copyright release for printing unlimited sets of plans and making modifications.

5 or 8 Prints (Single Build)

Five or eight printed sets of working drawings shipped to you. This option comes with a license to build ONE home.

5 Prints + PDF (Single Build)

Five printed sets of working drawings shipped to you, plus a digital version in PDF format. This option comes with a license to build ONE home and includes a copyright release for printing unlimited sets of plans and making modifications.

PDF (Multi Build)

A complete set of working drawings delivered in digital PDF format. This option comes with a license to build an UNLIMITED number of homes and includes a copyright release for printing unlimited sets of plans and making modifications. This option may not be available for all house plans, or may require a specific format to be purchased. Please call 770-831-6363 for more information.

CAD + PDF (Multi Build)

A complete set of working drawings delivered in digital DWG and PDF formats. AutoCAD files are used by design professionals to make significant modifications or engineering calculations to the plan. This option comes with a license to build an UNLIMITED number of homes and includes a copyright release for printing unlimited sets of plans and making modifications. This option may not be available for all house plans, or may require a specific format to be purchased. Please call 770-831-6363 for more information.

Choose a building foundation for your home. The foundation provides stability to a home's structure from the ground up.

Slab - This concrete foundation is reinforced with steel rods and suitable for flat ground.

Crawl Space - This foundation is raised off the ground with low walls resting on footings, providing space for wiring, plumbing, and storage.

Basement - This foundation is entirely or partially below ground and offers storage or living areas.

Walkout Basement - This foundation is typically suited for rear-sloping lots and provides storage or living areas. Walkout basements have doors that provide access to the outside.

Readable Reverse
An option to reverse the plan including texts and dimensions to make them readable.
2x4 or 2x6 Conversion
Convert the exterior framing other than the standard framing included in the plan.
Multi Build Licence (CAD required) Gives the buyer the legal right to build the house plan multiple times
What Makes Us Different
Them
Cost to Build
$30+
Shipping
Free
on physical blueprints
$20+
Price Guarantee
By 10%
beat competitor
Only Price Match
Purchase
Direct
from the Architect
Middleman
