Floor Plan

Stunning Ridge House Plan: Spacious Design with Artistic Layout

Discover a luxurious ridge house plan that offers a total living area of 2,682 sq. ft., blending spaciousness with thoughtful design. The first floor features an open floor plan, showcasing a grand great room with a cozy fireplace, seamlessly connecting to the kitchen equipped with a kitchen island and a convenient butler's pantry. Enjoy the first-floor owner's suite, complete with a master bath featuring a double vanity sink and walk-in closet. The home includes two additional bathrooms and a powder room for guests. A game room, home office, and hidden room provide versatility for work and leisure. Outdoor living is enhanced by a covered front porch and deck, while a three-bay courtyard garage offers ample space for vehicles. With a walkout basement and abundant storage options, this ridge house plan is perfect for comfortable living.

House Plan Specifications

  • Total Living (heated area):  2682 sq ft
    1st Floor:  2682 sq ft
    Basement:  1940 sq ft
    Total Porch:  956 sq ft
  • Garage:  1425 sq ft
    Garage Bays:   3
    Garage Load:   Courtyard
  • Bedrooms:   2
    Bathrooms:   3
    Half Bathrooms:   2
  • Foundation:   Walkout Basement
    Wall Framing:   2x6
    Roof Pitch:  7:12
    Exterior Siding:   Stone Exterior
  • Width of House:  79'
    Depth of House:  97'-9''
    Building Height:  23'
  • First Floor Ceiling Height:  10'
    Basement Ceiling Height:  10'

Key Features

  • Butler's Pantry
  • Covered Front Porch
  • Deck
  • Eating Bar
  • Fireplace
  • First Floor Master Suite
  • Game Room
  • Great Room
  • Hidden Room
  • Home Office/Study
  • Jack and Jill Bathroom
  • Kitchen Island
  • Laundry 1st Floor
  • Master Bath-Double Vanity Sink
  • Mud Room
  • Open Floor Plan
  • Outdoor Fireplace
  • Split Bedroom
  • Storage Space
  • Two-Story Grand Room
  • Unfinished Space
  • Walk-in Pantry
  • Wet Bar
