Rustic Barndominium with Wraparound Porch and Second-Floor Master Suite

42539 Natalie Barndominium is a two-story rustic-style residence providing 2,042 sq ft of heated living space, designed for a footprint of 83 ft 8 in in width by 48 ft 8 in in depth. The exterior is defined by an expansive 801 sq ft wraparound porch, which anchors the structure and creates a deep threshold between the interior living zones and the surrounding property.

The main level encompasses 1,147 sq ft, organized around an open-concept core that integrates a keeping room and a centralized kitchen equipped with a large island and a dedicated walk-in pantry. A private home office occupies a quiet corner of the floor, while the layout includes clustered bedrooms to consolidate the sleeping quarters. A half bathroom is located on this level to serve guests, maintaining separation from the full bathrooms situated elsewhere in the home.

Spanning 895 sq ft, the second floor is reserved for the primary suite, which provides an elevated level of privacy away from the primary social areas. The vertical profile of the home reaches a maximum building height of 27 ft, with 9-foot ceiling heights on the first floor and 8-foot ceiling heights on the second floor. The roof structure utilizes a combination of 8:12 and 4:12 roof pitches, contributing to the distinct barndominium aesthetic.

Practical utility is addressed through a massive 1,616 sq ft front-load 3-car garage, which offers significant storage capacity for vehicles and equipment. This garage integration is scaled to complement the overall house width, ensuring the structure maintains a balanced presence on the lot. The design prioritizes clear circulation and efficient use of square footage across both levels.

Key Features: 3 bedrooms, 2 full bathrooms, 1 half bathroom, wraparound porch, 3-car front-load garage, central kitchen island, walk-in pantry, home office, two-story configuration, 8:12 and 4:12 roof pitch.

Explore floor plans, available formats, and modification options for this design.

View Sample Plan
What's Included in the House Plan:
  • Cover Page – Front elevation, general notes, design criteria, abbreviations, and symbols
  • Elevations – Scaled front, rear, and side views, plus roof aerial
  • Foundation Plans – Engineered for slab or basement
  • Main Floor Plan – Fully dimensioned for framing, with wall thickness notes
  • Second Floor Plan – Same detail as main floor
  • Electrical & Sections – Separate page with electrical layout and typical wall/stair sections
  • Technical Support – Plan-related assistance included
What's Not Included:
  • Architectural or Engineering Stamp: Handled locally if required.
  • Site Plan: Created locally when needed.
  • Mechanical Drawings: Heating, air equipment, and ductwork to be designed by subcontractors.
  • Plumbing Drawings: Pipe sizes and locations to be determined by subcontractors.
  • Energy Calculations: Handled locally if required.

House Plan Specifications

  • Total Living (heated area):  2042 sq ft
    All Unheated Under-Roof Areas  2417 sq ft
    Total Structure  4459 sq ft
    1st Floor:  1147 sq ft
    2nd Floor:  895 sq ft
    Front Porch:  801 sq ft
  • Garage:  1616 sq ft
    Garage Bays:   3
    Garage Load:   Front
  • Bedrooms:   3
    Bathrooms:   2
    Half Bathrooms:   1
  • Foundation:   Slab
    Wall Framing:   2x4
    Roof Framing:   Stick
    Roof Pitch:  8:12 and 4:12
  • Width of House:  83'8''
    Depth of House:  48'8''
    Building Height:  27'
  • First Floor Ceiling Height:  9'
    Second Floor Ceiling Height:  8'

Key Features

  • Cluster Bedroom
  • Covered Front Porch
  • First Floor Laundry
  • Home Office/Study
  • Keeping/Family Room
  • Kitchen Island
  • Second Floor Master Suite
  • Walk-in Pantry
