Wilbury ADU is a compact two-story carriage house plan providing 650 sq ft of total heated living area within a 32-ft wide by 25-ft deep footprint. Designed with a 10:12 roof pitch and reaching a maximum building height of 27 ft 11 in, this structure utilizes a truss roof system and durable 2x6 exterior wall framing to ensure long-term structural integrity. Its vertical profile is characterized by a high-pitch roofline that maximizes interior volume while maintaining a modest 710 sq ft total footprint.
The first level consists entirely of a 650 sq ft, 2-car front-load garage. With 10-ft ceiling heights, this space provides clearance for vehicles, storage, or a dedicated workshop area. A side porch entry facilitates exterior access and creates a clear transition into the ground-level utility zone before moving to the upper living quarters.
The second floor contains the primary living area, which includes 650 sq ft of heated space featuring 9-ft ceiling heights. The layout incorporates a keeping room for social use and a private master suite. A key organizational feature is the direct integration of laundry access through the master walk-in closet, which optimizes floor space and improves daily circulation within the private living zone.
This dwelling is engineered for versatility, serving as a detached rental unit, guest house, or personal retreat. The combination of a 2-car garage capacity and a self-contained upper apartment makes it an efficient solution for properties requiring additional living quarters without increasing the primary home's footprint.
Key Features: 1 bedroom, 1 bathroom, 650 sq ft living area, 2-car front-load garage, 10:12 roof pitch, 9-ft and 10-ft ceiling heights, laundry access via master closet, truss roof system, 2x6 exterior wall framing, ADU utility.
