Charming One-Bedroom Retreat is a 1,008 sq ft single-story residence engineered with a 60'3" frontage and 25'4" depth. This compact footprint prioritizes efficient circulation through a 1-bedroom, 1.5-bath configuration, making it a viable solution for ADU-style living or a minimalist primary residence. The exterior architecture utilizes a dual-pitch roof system with 12:12 and 2:12 slopes, contributing to an 18'8" maximum building height that provides a distinct profile.
The interior is organized around an open-concept core, where the great room serves as the central hub for the floor plan. A kitchen island with an integrated eating bar acts as a physical divider between the culinary space and the living area, maintaining direct sightlines throughout the primary zone. The 9-foot ceiling heights increase the perceived volume of the 1,008 square feet of heated living space, allowing for enhanced natural light penetration.
Private quarters consist of a master suite that includes a walk-in closet and access to a full bathroom. A secondary half-bathroom is positioned to support guest use while preserving the privacy of the primary suite. The total 1,155 square feet of under-roof space includes 147 square feet of porch area, divided between covered front and rear porch structures that extend the living envelope to the exterior.
The structural design is optimized for a slab foundation, utilizing a simple layout that maximizes interior square footage by minimizing hallway space. With 1,008 square feet of living area, the home provides a balance of utility and comfort for single-level requirements. The exterior wall and roof framing are specified to support the 8-inch roof pitch variations, ensuring durability and a consistent aesthetic across all elevations.
Key Features: 1 bedroom, 1.5 bathrooms, 1,008 sq ft heated area, 9-foot ceilings, kitchen island with eating bar, walk-in closet, covered front and back porches, slab foundation, 60'3" width, 18'8" maximum building height.
Explore floor plans, available formats, and customization options for this design.
The construction drawings will include detailed, dimensioned floor plans, exterior elevations, roof plan, foundation plan, basic electrical layout, cross-section(s), foundation plan, and other general specifications. Some plans will include interior cabinet layouts.
View Sample Plan
