Simplistic lines and a neutral color palette define this modern design and allow the accent materials and details to come alive. Timber lintels and columns in a dark stain contrast with the white cladding. Shed dormers add interest and provide natural light to the interior. Board-and-batten siding along with painted brick are the base materials of choice and are understated. The main level is fresh and modern with features galore such as the master suite, open concept living and dining space and a fully appointed kitchen. The guest suite and/or home office is perfectly located for quiet and privacy for the telecommuter or visiting family member. Storage is well thought out with the use of walk-in closets, large pantry, mud room, and laundry space. The rear covered porch adds extra living and dining area which let the owners get outdoors when the seasons cooperate. The upper level completes the home with two additional sleeping rooms, a compartmentalized bath and loft - perfect for reading, homework or just relaxing. The optional bonus room can be finished toe add square footage that has many uses - recreation, exercise, media or great storage.

Key Benefits:
  • Craftsman Style: The Madison Park House Plan (K1674-A) features a craftsman design with modern conveniences.
  • Open-Concept Layout: The floor plan fosters connectivity between living areas, ideal for family living.
  • Master Suite Comfort: The master suite offers a private retreat with luxurious amenities.
  • Outdoor Living: Includes covered porches that extend the living area outdoors.
  • Bonus Room: Provides additional space that can be adapted for a home office or guest suite.
  • Square footage: 2711.

House Plan Specifications

  • Total Living (heated area):  2711 sq ft
    1st Floor:  1941 sq ft
    2nd Floor:  770 sq ft
    Bonus Room:  344 (Optional) sq ft
    Basement:  1941 sq ft
    Total Porch:  56 sq ft
  • Garage:  530 sq ft
    Garage Bays:   2
    Garage Load:   Side
  • Bedrooms:   3
    Bathrooms:   3
    Half Bathrooms:   1
  • Foundation:   Slab
    Wall Framing:   2x4
    Roof Framing:   Stick
    Roof Pitch:  10:12
    Exterior Siding:   Brick Exterior
  • Width of House:  50''
    Depth of House:  73'-5''
    Building Height:  30'-6''
  • First Floor Ceiling Height:  9'

Key Features

  • Bonus Room
  • First Floor Laundry
  • First Floor Master Suite
  • Formal Dining Room
  • Home Office/Study
  • Keeping/Family Room
  • Laundry 1st Floor
  • Master Bath-Double Vanity Sink
  • Mud Room
  • Two-Story Foyer
  • Vaulted/Volume Ceilings
  • Walk In Closets
  • Walk-in Closet
  • Walk-in Pantry
