Edison 2 occupies a 44-foot wide by 32-foot deep footprint, providing 1,183 square feet of heated living space in a single-level configuration. This Craftsman design utilizes a 7:12 roof pitch and a maximum building height of 17 feet 1 inch to establish a compact, vertical profile suitable for smaller lots while maintaining traditional architectural proportions.
The interior layout centers on an open-concept core where the living room, dining area, and kitchen maintain direct sightlines to maximize the 1,183-square-foot floor plate. A first-floor primary suite is positioned for privacy, featuring an attached bathroom and walk-in closet. Two additional bedrooms are located on the main level, providing flexible options for a home office or guest quarters.
Structural details include 8-foot ceiling heights throughout the primary living zones, which contribute to a consistent volume across the floor plan. The exterior envelope is characterized by a 43-square-foot covered front porch and a 21-square-foot side stoop, providing transition points between the interior and exterior environments. The cladding features a combination of board and batten siding with shake accents to define the building’s aesthetic.
Practical utility is integrated through a first-floor laundry room and dedicated storage zones, ensuring the square footage is allocated to support daily requirements. The foundation and structural framing are designed to support the 1,183-square-foot structure, balancing material efficiency with the established Craftsman style requirements.
Key Features: 3 bedrooms, 2 bathrooms, 1,183 square feet, single-story, Craftsman style, 8-foot ceilings, 7:12 roof pitch, 43-square-foot covered front porch, first-floor primary suite, first-floor laundry.
Review floor plans, dimensions, and customization options for the Edison 2 house plan to prepare for your project.
