Eastside 4 is a 1,254 square foot ranch-style residence characterized by a 52-foot width and a 30-foot 8-inch depth, making it a viable configuration for narrow to mid-sized residential lots. The exterior profile is defined by a 6:12 roof pitch and a 15-foot 4-inch maximum building height, providing a traditional aesthetic while maintaining a compact vertical footprint suitable for single-level living.
The interior floor plan utilizes 1,254 square feet of heated space to accommodate a three-bedroom, two-bathroom layout. The central living core includes a designated keeping room and a formal dining area, which provides a transition between the kitchen and the primary living spaces. The kitchen features a wall pantry, maximizing storage within the footprint, while the master suite is positioned to ensure privacy from the secondary bedrooms.
Technical specifications for this home include 8-foot ceiling heights throughout the primary level, creating a consistent volume across the living zones. The structural assembly utilizes 2x4 wall framing combined with stick roof construction. These elements are chosen to balance build efficiency with long-term structural integrity for a standard residential application.
Outdoor utility is integrated through a 111-square-foot total porch area, which includes a 90-square-foot covered front porch and a secondary side stoop. These additions extend the usable square footage for exterior transitions. The design prioritizes a straightforward circulation path, ensuring that the laundry facilities and utility areas are positioned for direct access from the primary living corridors.
Key Features: 1,254 sq ft heated area, 3 bedrooms, 2 bathrooms, 6:12 roof pitch, 8-foot ceiling height, covered front porch, wall pantry, keeping room, master suite, stick roof construction, 2x4 wall framing.
